Description
Hardware Specifications |
||
|---|---|---|
CPU |
CPU Model | Intel Celeron J4125 |
| CPU Architecture | x64 64-bit | |
| CPU Frequency | Quad Core 2.0GHz (burst up 2.70 GHz) | |
MEMORY |
Memory | 4GB SO-DIMM DDR4 |
| Memory Module Pre-installed | 4GB (1 x 4GB) | |
| Total Memory Slots | 2 | |
| Memory Expandable up to | 8GB (2 x 4GB)
|
|
| Flash Memory | 8GB eMMC | |
STORAGE |
HDD | 2 x SATA3 6Gb/s; 3.5″/2.5″ HDD/SSD |
| M.2 Drive Slots (SSD Cache) | 2x M.2 PCIe (NVMe) *M.2 2280 |
|
| Maximum Internal Raw Capacity | 36 TB (18 TB HDD X 2, Capacity may vary by RAID types) | |
| Maximum Drive Bays with Expansion Unit | 14 | |
| Maximum Raw Capacity with Expansion Units | 252 TB (18 TB HDD X 14, Capacity may vary by RAID types) | |
EXTERNAL PORTS |
Expansion | USB 3.2 Gen 1 x3 |
| Network | 2.5 Gigabit Ethernet x 2 | |
| HDMI Output | HDMI 2.0a x1 | |
OTHERS |
System Fan | 70mm x 1 |
| Infrared Receiver | ||
| Power Supply Unit / Adapter | 65W x1 | |
| Input Power Voltage | 100V to 240V AC | |
| Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC | |
OPERATION |
Power Consumption | 15.9 W (Operation); 9.2 W (Disk Hibernation); 0.66 W (Sleep Mode) |
| Noise Level | 17.7dB (HDD idle) | |
| Operation Temperature | 0°C~40°C (32°F~104°F) | |
| Humidity | 5% to 95% RH | |
SIZE AND WEIGHT |
Size | 163.5(H) x 108(W) x 230(D) mm |
| Weight | 2 kg / 4.4 lb | |
