Description
| Model | AS7112RDX |
| CPU | CPU Model Intel Xeon E-2224 CPU Architecture x64 64-bit CPU Frequency Quad-Core 3.4GHz up to 4.6GHz |
| Memory | Memory 8GB DDR4 ECC UDIMM Memory Module Pre-installed 8GB (1 x 8GB) Total Memory Slots 4 Memory Expandable up to 128GB (4 x 32GB)Support mixed capacity Flash Memory 8GB USB DOM |
| Storage | Drive Bays 12 M.2 Drive Slots 2 Compatible Drive Type3.5″ SATA HDD 2.5″ SATA HDD 2.5″ SATA SSD M.2 22110 NVMe M.2 2280 NVMe M.2 2280 SATA 3 M.2 2260 SATA 3 M.2 2242 SATA 3 Maximum Drive Bays with Expansion Unit 20 |
| External Ports | Expansion USB 3.2 Gen 2 x 4 Type-A ; USB 3.2 Gen 2 x 2 Type-C Network Gigabit Ethernet x 4 (1G/100M) PCIe Expansion Slots PCIe Expansion Slots: 2 x Gen3 x4 slots (x4 link) ; 1 x Gen3 x8 slots (x8 link) for optional 10/25/40/50 GbE card and SAS card HDMI Output N/A |
| Others | System Fan 60mm x 3 Power Supply Unit / Adapter 550W x2 Input Power Voltage 100V to 240V AC Redundant power supply Service LED Indicator Certification FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS Warranty 5 Years |
| Operation | Power Consumption 92.4W (Operation); 45.5W (Disk Hibernation) 7.55 W (Sleep Mode); Noise Level N/A Operation Temperature 0°C~40°C (32°F~104°F) Humidity 5% to 95% RH |
| Size and Weight | Size 88(H) x 439(W) x 535(D) mm Weight 13 (kg) / 28.6(lb) |
